Ceiling and wall mounted luminaire

Milano Slim

MILANO SLIM is total light. 360 degree office light. Light that radiates in all its forms, directly, indirectly and laterally. Light which spreads beautifully outwards, distilled and refined by the frosted diffuser design. Easily mounted, full of features but free of glare, it can grace any office.



Features Features
  • Cylindrical diffuser just 58 mm, timeless design
  • Direct-indirect light emission, omni-directional
  • 2 optics, new: suitable for application in offices thanks to microprismatic C-LED optics. Diffuser omnidirectional
  • Standard-compliant C-LED optics according to EN 12464-1 ensure perfect glare control and light suitable for office use
  • Suitable for application in offices thanks to microprismatic C-LED optics. All-round diffuser
  • Diffuser made of high-grade plastic, attractive
  • Extremely homogenous omnidirectional illumination
  • Highly Efficient state-of-the-art LEDs, up to 173 lm/W
  • LED board and optics replaceable
  • Colour temperature can be adjusted individually with the Tunable White technology
Specifications Specifications
  • Luminaire for mounting on walls and ceiling, and for pendant mounting
  • Diameter diffuser: 430 mm, 530 mm, 680 mm
  • Pendant tube 1 m long as standard; can be shortened on site
  • C-LED optics consisting of an inserted microprismatic plate in a transparent diffuser
  • Pendant tube with ball and socket joint, self-adjusting up to 20°
  • Other types of pendant possible thanks to accessories (3 m can be shortened on site, surface mounted and pendant luminaire)
  • Operating unit integrated
  • Suitable for emergency lighting (DC-compatible)
  • Ceiling and wall mounted luminaire available with emergency unit
  • Light control: DALI or Casambi

Fields of application Fields of application
  • Office & Education
    classrooms, meeting rooms, offices, reception rooms, cafeterias, foyers and lobbies, corridors
  • Retail & Hospitality
    hotels, reception areas, circulation zones

Version
0 Article
Diameter
430 mm
530 mm
680 mm
System power
13 W
17 W
22 W
23 W
24 W
33 W
34 W
35 W
36 W
60 W
Colour temperature
3000 K warm white
4000 K neutral white
6500 K Tunable White
Light control
DALI
Casambi
emergency unit
with emergency unit
