Pendant luminaire

Solo Slim Office

SOLO SLIM integrates itself harmoniously into any architecture thanks to its round design. Whether as a ceiling, pendant or freestanding luminaire – SOLO SLIM spreads pleasant light everywhere. The elegant and uniform design makes the luminaire an aesthetic highlight for any room.



Features Features
  • Height of frame only 53 mm, white
  • Aluminium housing
  • Extremely even spread of light across the opal diffuser or microprismatic C-LED optics, suitable for application in offices
  • Recessed ceiling luminaire with or without trim or especially recessed in concrete
  • Ceiling mounted luminaire optional halo effect through indirect component (8 %)
  • Pendant luminaire direct-indirect light emission (61 % / 39 %)
  • LED board and optics replaceable
Specifications Specifications
  • Up to 4 diameters depending on the mounting type: ca. 400 mm, 500 mm, 650 mm, 950 mm
  • Optics, suitable for application in offices according to EN 12464-1 with Glare control: up to UGR < 16 and maximum luminance up to Lmax ≤ 3000 cd/m2
  • Electronic control integrated
  • Light control: DALI or Casambi
  • Suitable for emergency lighting (DC-compatible)
  • Available with emergency unit
  • Pendant tube 1 m long as standard; can be shortened on site
  • Other types of pendant possible thanks to accessories (3 m can be shortened on site, surface mounted and pendant luminaire)
  • IP44 kit optional
  • Also available recessed ceiling, ceiling, pendant and freestanding luminaire

Fields of application Fields of application
  • Office & Education
    classrooms, meeting rooms, offices, cafeterias, foyers and lobbies, corridors, staircases
  • Retail & Hospitality
    hotels, reception areas, circulation zones
Version
0 Article
PROH_9306_TK.jpg Mounting accessories to be ordered separately
Diameter
530 mm
980 mm
System power
21 W
43 W
48 W
49 W
101 W
Colour / Finish
silver
white
Colour temperature
3000 K warm white
4000 K neutral white
6500 K Tunable White
Light control
DALI
Casambi
Notes
Casambi Tunable
